FPC P1.00 SMT 22P NON-ZIFA upright

This job specification is suitable for: 1.0 PITCH FPC CONNECTOR,NON-ZIF VERTICAL SMT Connection with FPC/FFC: NON-ZIF; FPC/FFC suitable thickness: 0.30±0.05mm

Key words:

ARC

Classification:

FPC Series

Online message

Detail description

1 Scope of application

This job specification is suitable for: 1.0 PITCH FPC CONNECTOR,NON-ZIF VERTICAL SMT

Connection with FPC/FFC: NON-ZIF;

FPC/FFC suitable thickness: 0.30±0.05mm

2 Associated Specifications

EIA-364 : Test Procedures for Electronic Connectors and Connectors

UL STD-94 : Specifications for testing the flame retardancy of plastic equipment parts and equipment

3 Construction Dimensions Material

See construction drawing Materials

parts

Suppliers of raw materials

Material name/Type name

FLAME CLASS

FILE NO.

main body

(HOUSING)

Polyplastics

POLYPLASTICS CO., LTD

LCP

Liquid crystal polymer

473i (natural color)

V-0

E106764

4 standard status

4.1 Rated voltage: AC/DC 125V

4.2 Rated current: 0.5A

4.3 Temperature and humidity range

4.3.1 Operating temperature range: -40~85℃;

4.3.2 Storage temperature range: -40~85℃;

4.3.3 Storage humidity range: relative humidity below 90%RH.

5 performance

5.1 Structure

serial number	project	Test Methods	Specifications
1	Exterior	Visual inspection, inch measurement.	Meet the drawing requirements

5.2 Electrical properties

serial number	project	Test Methods	Specifications
1	contact resistance	Test on the same terminal, current: 1.0A (DC), voltage: below 5V, use wire: adapt to FFC standard wire.	30mΩ Max.
2	Insulation resistance	DC 500V between adjacent terminals, 1 minute.	100MΩ Min.
3	Pressure test	AC 500V between adjacent terminals, induction current 2mA, 1 minute.	No breakdown, no short circuit.
4	The temperature rises	When the terminal is working at rated voltage and current, measure the temperature rise of the terminal.	30℃ Max.

This product does not contain environmental substances prohibited by SS-00259 and RoHS

5.3 Mechanical properties

	project	Test Methods	Specifications
1	FFC/FPC holding force	After the FFC is inserted into the FPC connector, it is pulled out vertically at a constant speed of 25~100mm/min. After this action is repeated three times, the measurement data is recorded for the fourth time.	SEE "FFC/FPC Retention Force"
2	Terminal retention	Pull out the terminal vertically from the rubber core groove at a constant speed of 25~100mm/min	300gf/terminal Min.
3	Plug Durability	Perform 10 rounds of the following moves: FPC insertion, FPC extraction	Contact resistance 50mΩ Max . No deformation

5.4 Durability

serial number	project	Test Methods	Specifications
1	Vibration resistance	The terminals are connected in series with a current of 0.1A DC, an amplitude of 1.5mm, a frequency of 10-55-10Hz, and X, Y, and Z directions for 2 hours each, for a total of 6 hours.	Contact resistance 50mΩ Max. Discontinuous conduction within 1μs; no abnormal appearance.
2	Impact resistance	The terminals are connected in series with a current of 0.1A DC, the acceleration is 490m/s ² , the X, Y, and Z directions are 11ms each, 3 times each, 18 times in total.
3	cold resistance	Place at -25±3°C for 48H.	1 Contact resistance: 50mΩ Max. 2 Insulation resistance: 100 MΩ Min. 3 withstand voltage: no breakdown, short circuit 4 Appearance: no abnormality
4	heat resistance	Place it at a temperature of 85±2°C for 96 hours.
5	Moisture resistance	The temperature is 40±3℃; the storage time is 96H in the humidity of 90~95% RH.
6	Salt spray test	Temperature 35±2℃; Salt water specific gravity 5±1% Spray test: A: Gold plating 48h B: Tin plating 16h C: Single pin terminal 48h
7	Thermal shock	-55±3°C; 85±2°C for 30 minutes each, for a total of 5 cycles.
8	Moisture resistance (temperature and humidity cycle)	Follow the curve below to complete the 5 cycle test.
9	Tin Wetting	Dipping tin temperature 245±3℃ (Sn: Lead Free); time 3s Max.	eat tin full, Above 95%.
10	Solder heat resistance	Soldering iron temperature 350±10℃ (Sn: Lead Free); time 10+1/-0s.	meet the electrical performance, Appearance is normal, Tin foot and fixed piece are flat Roundness 0.10mm Max.
11	Reflow heat resistance	Preparatory heating time: 150°C 60~120s. Soldering temperature time: 250℃ 30±1s.
12	Sulfur resistance (gold-plated product)	According to the technical standard SS-00126-12 three kinds of mixed GAS corrosion test.	Contact resistance: 50mΩ Max. No visible corrosion near contacts.
13	Solvent resistant	Place product in isopropyl alcohol container for 90 seconds and remove.	meet the electrical performance, Appearance is normal.

6 packs

see bundle diagram
